Cold-Rolled Oriented Silicon Steel

Cold-rolled oriented silicon steel, also known as cold-rolled transformer steel, is an important ferrosilicon alloy used in transformer (iron core) manufacturing industry. Its production process is complex and its manufacturing technology is strict. It is mainly divided into common oriented silicon steel (CGO) and high magnetic induction oriented silicon steel (Hib) .

Take Action

Brief Introduction

Oriented Electrical Steel: ore-iron-steel-hot rolled-pickled-cold rolled-annealed-cold rolled silicon steel (oriented electrical steel) .

Cold-rolled oriented silicon steel is mainly used to make transformer core.Cold-rolled oriented silicon steel strip is made of 0.30 or 0.35 mm oriented silicon steel strip, which is pickled, cold-rolled and annealed. The cold-rolled non-oriented silicon steel sheet is the billet or continuous casting billet hot-rolled into a thickness of about 0.23 mm strip. The cold-rolled silicon steel strip has the characteristics of smooth surface, uniform thickness, high stacking coefficient and good punching property, and has higher magnetic induction and lower iron loss than the hot-rolled silicon steel strip. Using cold strip instead of hot strip to make motor or transformer, its weight and volume can be reduced by 0% -25% . If the cold-rolled oriented strip is used instead of the hot-rolled strip or the low-grade cold-rolled strip, the power consumption of the transformer can be reduced by 45% -50% , and the performance of the transformer is more reliable.

Product Introduction

Oriented silicon steel material contrast table
	(mm)	Baosteel	WISCO	NSC	JFE	Congent	TKS	Posco	NI & SCo	AK
Normal	0.23	B23G110	23Q105
			23Q110	23Z110			C110-23		NV23S -
			23Q115
		B23G120				M120 -	C120-23		NV23S -	M-3
						M127 -	C127-23		NV23S -
	0.27							27PG110	NV27S -
		B27G120	27Q120	27Z120	27JG120		C120-27	27PG120	NV27S -	M-4
		B27G130	27Q130	27Z130	27JG130	M130 -	C130-27	27PG130	NV27S -	M-4
			27Q140			M140 -	C140-27		NV27S-14
	0.3							30PG110
		B30G120	30Q220	30Z120	30JG120			30PG120	NV30S -
		B30G130	30Q180	30Z130	30JG130		C130-30	30PG130	NV30S -
		B30G140	30Q160	30Z140	30JG140	M140 -	C140-30	30PG140	NV30S -	M-5
			30Q150			M150 -	C150-30			M-5
			30Q140
			30Q130
			30Q120
	0.35	B35G135	35Q135	35Z135	35JG135				NV35S -
		B35G145	35Q145	35Z145	35JG145	M150 -	C150-35	35PG145	NV35S -	M-6
		B35G155	35Q155	35Z155	35JG155	M165 -	C165-35	35PG155		M-6
High magnetic induction type	0.23	B23P090	23QG090	23ZH090	23JGS090 23JGH090	M90 -23P5	H090-23	23PH090
		B23P095	23QG095	23ZH095	23JGS095 23JGH095		H095-23	23PH095
		B23P100	23QG100	23ZH100	23JGH100	M100 -	H100-23	23PH100		H-0
				23ZH110
	0.27						H090-27
		B27P095	27QG095	27ZH095			H095-27	27PH095
		B27P100	27QG100	27ZH100	27JGH100	M103 -	H103-27	27PH110	NV27P-
		B27P110	27QG110	27ZH110	27JGH110					H-1
	0.3	B30P100	30QG100	30ZH100	30JGH100			30PH100
		B30P105	30QG105	30ZH105	30JGH105	M105 -	H105-30	30PH105	NV30P-
		B30P110	30QG110	30ZH110	30JGH110	M111 -	H111-30
		B30P120	30QG120	30ZH120	30JGH120	M117 -
	0.35	B35P115		35ZH115	35JGS115 35JGH115			35PH115
		B35P125		35ZH125	35JGS125 35JGH125			35PH125
		B35P135		35ZH135	35JGH135			35PH135
High magnetic induction type with domain refinement	0.23	B23R080		23ZDKH80 23ZDMH8	23JGSD80			23PHD080
		B23R085		23ZD0KH85 23ZDMH8	23JGSD85		H085-23	23PHD085
		B23R090		23ZD5KH90 23ZDMH9	23JGSD90		H090-23			H-0DR
	0.27	B27R090		27ZD0KH90 27ZDMH9	27JGSD90		H090-27	27PHD090
		B27R095		27ZD0KH95 27ZDMH9	27JGSD95			27PHD095		H-1DR
